PitcoSolsticeandSolsticeSupremeHighEfficiencyGasFryers



SG/SSHSeriesServiceManual 40
ReplacingtheFrypot
1. Remove the controller front panel, gas valve,
pilot assembly, and burner assembly.
2. Remove the baffle by pulling it out.
NOTE: For SSH models only.
3. Remove the drain manifold flange nut using a
9/16 inch close-ended wrench.
4. Loosen the collet using a spanner wrench.
5. Remove the collet.
6. Slide piping aw
ay from flange.
