DA80F/DA95F AddressRight™ Printers Service Manual (SV61962 Rev. A)
2-3
Specifications • 2
Fonts
Resident Fonts
Arial, Comic Sans MS, Courier New, Georgia, Impact, Kino, MSLogo, Sym-
bol, Tahoma, Times New Roman, Trebuchet MS, Verdana, Webdings, Wing-
dings, plus there must be included one OCR and one Code 39 font. (All fonts
are scalable from 4 to 108 pt size.)
Resident Font Enhancements
Bold, Underline, Italic
Downloadable Fonts
Supports TrueType and Bitmapped fonts.
Downloadable Graphics
Supports Bitmap and PCL Raster images up to 40 sq in. (258 sq. cm). This
translates to images up to 3" x 13.3" (76mm x 338mm) for the DF95.
User-Definable Parameters
• Font Characteristics
• Address Placement
• Barcode Characteristics
• Print Quality
Barcode Printing Position
The printer can print a barcode in one of three positions:
• Above the address block
• Below the address block
Print Modes (Print Resolution)
The printers have four print resolutions; they are Executive (600 DPI), Letter
(300 DPI), Draft (200 DPI), and Super Draft (150 DPI), which represent the
horizontal density. Additionally, there are two Light Mode settings (ON and
OFF), which represent the vertical density. When Light Mode is “ON”, the
vertical density setting is 300 DPI; when Light Mode is “OFF” the vertical den-
sity setting is 600 DPI. Refer to the table below for print mode options.
Print Quality With Light Mode set to
"ON"
With Light Mode set to
"OFF"
Executive 600 x 300 DPI 600 x 600 DPI
Letter 300 x 300 DPI 300 x 600 DPI
Draft 200 x 300 DPI 200 x 600 DPI
Super Draft 150 x 300 DPI 150 x 600 DPI
2.4 Print
Specifications
