Printer Control Panel Menus and Utilities • Appendix A
1. Adjust Printing
A.5 LCD
Service Menu
Menu Option Settings What It Does
A - Print Head Adjust
[for Print heads 1-3]
Horiz Adj: HDS 2-1
(A-O)
Allows you to adjust the horizontal
alignment of heads 1 and 2
Horiz Adj: HDS 3-2
(A-O)
Allows you to adjust the horizontal
alignment of heads 2 and 3
Vertical Adjust 2-1
(1-9)
Allows you to adjust the vertical
alignment of heads 1 and 2
Vertical Adjust 3-2
(1-9)
Allows you to adjust the vertical
alignment of heads 2 and 3
Mod A to Sensor
+/- 0.500 inch (in
0.001 inch incre-
ments)
Allows you to modify a nominal set-
ting that affects the distance from
the sensor to the print head you are
aligning
B - Print Head Adjust
[for Print heads 4-6,
DA95F Only]
Horiz Adj: HDS 5-4
(A-O)
Allows you to adjust the horizontal
alignment of heads 4 and 5
Horiz Adj: HDS 6-5
(A-O)
Allows you to adjust the horizontal
alignment of heads 5 and 6
Vertical Adjust 5-4
(1-9)
Allows you to adjust the vertical
alignment of heads 4 and 5
Vertical Adjust 6-5
(1-9)
Allows you to adjust the vertical
alignment of heads 5 and 6
Mod B to Sensor
+/- 0.500 inch (in
0.001 inch incre-
ments)
Allows you to modify a nominal set-
ting that affects the distance from
the sensor to the print head you are
aligning
✍
TIP: See Appendix
D - Print Head Align-
ment for the full pro-
cedure to adjust the
print heads.
✍
TIP: The Print Head
Alignment procedure
should be done each
time the print cartridge
is replaced.
