Pitney Bowes DA80F - Transport Timing Belt

5-12 DA80F/DA95F AddressRight™ Printers Service Manual (SV61962 Rev. A)
5 • Removal and Replacement
3. Slide auto-tensioner back to release tension on belt, then re-tighten
screw. Slowly walk the belt off the feed pulley assembly.
4. Install new belt. Loosen screw, tension new belt, then re-tighten screw.
5. Replace cover.
Screw for Auto-Tensioner
Transport Timing Belt
Auto-Tensioner
DA80F (WF81) Parts Removal
5.9 Transport
Timing Belt
1. Remove the front bottom cover (see section 5.8).
2. Loosen the auto-tension screw.
