4-6 DA80F/DA95F AddressRight™ Printers Service Manual (SV61962 Rev. A)
4 • Troubleshooting/Diagnostics
4.3 Main
Controller
Board
Diagnostics
Location Description Comments/Models Used On
J1 Print Head 1 Bank A
J2 Print Head 2
J3 Print Head 3
J4 Print Head 4 Bank B
DA95F only
J5 Print Head 5
J6 Print Head 6
J10 Serial Debug Port (Engineering use
only)
Allows attachment of a serial
device to communicate with the
board
J11 W98x Series Stacker Allows communication to
Pitney Bowes stackers: W980,
W981, W983, W984, W985,
W986
J12 Third Party Stacker/Conveyor DA80F only
J15 Feeder Motor
Feeder Motor Encoder
Feeder Sensors
DA95F only
J18 LAN
J20 USB
J21 External High Speed Feeder (only
used if you are replacing the stan-
dard WF9S feeder)
DA95F only
J22 Feeder Sensor Emitter DA80F only
J23 Input Power
J24 Feeder Sensor Receiver DA80F only
J25 LCD Display
J26 Feeder Motor DA80F only
J27 Transport Motor
J28 Exit Sensor Receiver DA95F only
J29 Exit Sensor Emitter DA95F only
J30 Not used currently
J31 Feeder Motor Encoder DA80F only
J32 Paper Sensor Emitter
J33 Paper Sensor Receiver
J34 Shaft Encoder
Table 4-1 Main Board Connectors
✍
TIP: See Appendix B
- Printer Communica-
tions, for troubleshoot-
ing problems relating to
networking and printer
communications.
