User Manual of WDAP-C7200AC/WDAP-W7200AC
-11-
2.1.1 Panel Layout
The front and rear panels provide a simple interface monitoring the AP. Figure 2-2 shows the hardware interface
of the WDAP-C7200AC.
WDAP-C7200AC Hardware Interface:
Figure 2-3 WDAP-C7200AC Panel Layout
WDAP-W7200AC Hardware Interface:
Figure 2-4 WDAP-W7200AC Panel Layout
