User Manual of WDAP-C7200AC/WDAP-W7200AC
-124-
Appendix B: FAQs
Q1: How to set up the WDS Repeater Connection
In this case, we use 2.4GHz wireless to connect to the root AP and then repeat the wireless signal by using the
2.4GHz wireless interface to let the 2.4GHz wireless clients surf the internet.
Topology:
1. Before configuration, please ensure the 2.4GHz root AP is already connected to the internet
and the DHCP server is enabled to let it able to assign IP address to the connected clients.
2. Please ensure there is no IP conflict in the existing network. Otherwise, please re-configure the
WDAP-C7200AC using other IP addresses which should be in the same network segment. The
default IP address of the WDAP-C7200AC is 192.168.1.253.
Step 1. In the WDAP-C7200AC-1, go to “WLAN2 (2.4GHz) Basic Settings” to configure wireless mode to
“WDS” and then configure the channel to a fixed one. Click “Apply Changes” to take effect.
Step 2. Go to “WLAN2 (2.4GHz) WDS Settings” page to connect the root AP. Select “Enable WDS” and
enter the MAC address of the repeater AP. Then, click “Set Security” to configure the security setting for the
WDS connection. After finishing the configuration, click “Apply Changes” to take effect.
