User Manual of WDAP-C7200AC/WDAP-W7200AC
-63-
i. Click “Start PBC” on the WPS page of the AP.
Figure 5-43 WPS-PBC – 5GHz-1
Figure 5-44 WPS-PBC – 5GHz-2
ii. Press and hold the WPS button equipped on the adapter directly for 2 or 3 seconds. Or you can click
the WPS button with the same function in the configuration utility of the adapter. The process must be
finished within 2 minutes.
iii. Wait for a while until the next screen appears. Click OK to complete the WPS configuration.
B. By Pin
If the new device supports Wi-Fi Protected Setup and the Pin method, you can add it to the network by Pin with
the following two methods.
Method One: Enter the Pin of your wireless adapter into the configuration utility of the AP
i. Enter the Pin code of the wireless adapter in the field behind Client Pin Number in the following
figure. Then click Start Pin.
The Pin code of the adapter is always displayed on the WPS configuration screen.
