User Manual of WDAP-C7200AC/WDAP-W7200AC
-47-
Step 4. Wait until the connection is established. Check the “Add to Wireless Profile” option and then reboot it.
Figure 5-31 Client – Status
 WDS
Connect this Wireless AP with up to 8 WDS-capable wireless APs to expand the scope of network.
 WDS
Connect this Wireless AP with up to 8 WDS-capable wireless APs to expand the scope of network.
AP
ClientsSwitch
ClientsSwitch
Clients Switch
WDAP-C7200AC
AP
WDS Bridge-PtMP Mode
Clients ClientsSwitch Switch
WDAP-C7200AC WDAP-C7200AC
WDS Bridge-PtP Mode
