User Manual of WDAP-C7200AC/WDAP-W7200AC
-18-
Step 5. Magnet Installation: To install the WDAP-W7200AC on a magnetic surface, simply follow the diagram
below:
Figure 3-10 WDAP-W7200AC Installation Diagram 5
Step 6. Plug the Ethernet cable into the PoE port.
Figure 3-11 WDAP-W7200AC Installation Diagram 6
