User Manual of WDAP-C7200AC/WDAP-W7200AC
-17-
Figure 3-8 WDAP-W7200AC Installation Diagram 3
Step 4. DIN-Rail Mounting Installation:
(1) Screw the DIN-rail on the WDAP-W7200AC
(2) Lightly push the bottom of DIN-rail into the track
(3) Check whether the DIN-rail is tightly on the track
Figure 3-9 WDAP-W7200AC Installation Diagram 4
