User Manual of WDAP-C7200AC/WDAP-W7200AC
-29-
Step 3: Wireless 5GHz Basic Settings
Figure 5-8 Wizard – Wireless 5GHz Basic Settings
The page includes the following fields:
Object Description
Band
Supports 802.11a, 802.11n, 802.11ac and mixed mode. Please choose its
band according to your clients.
Mode
Supports AP, Client, WDS and AP+WDS mode.
SSID
Service Set Identifier identifies your wireless network.
Channel Width
Select 80MHz if you use 802.11ac; select 40MHz if you use 802.11n;
otherwise, 20MHz is for the 802.11a mode.
Control Sideband
It is only valid when you choose a 40MHz channel width.
Channel Number
Indicates the channel setting for the AP.
Step 4: Wireless 5GHz Security Settings
Secure your wireless network by turning on the WPA or WEP security feature on the router. For this section, you
can set WEP and WPA-PSK security mode.
Figure 5-9 Wizard – Wireless 5GHz Security Setup
