User Manual of WDAP-C7200AC/WDAP-W7200AC
-44-
The page includes the following fields:
Object Description
Disable Wireless LAN
Interface
Check the box to disable the wireless function.
Band
Select the desired mode. Default is “5GHz (A+N+AC)”. It is strongly
recommended that you set the Band to “5GHz (A+N+AC)”, and all of
802.11a, 802.11n, and 802.11ac wireless stations can connect to the
WDAP-C7200AC/WDAP-W7200AC.
5 GHz (A): 802.11a mode, rate is up to 54Mbps
5 GHz (N): 802.11n mode, rate is up to 300Mbps
5 GHz (AC): 802.11n mode, rate is up to 867Mbps(2T2R)
5 GHz (A+N): 802.11a/n mode, rate is up to 300Mbps
5 GHz (N+AC): 802.11n/ac mode, rate is up to 300Mbps or
867Mbps
5 GHz (A+N+AC): 802.11a/n/ac mode, rate is up to 54Mbps,
300Mbps, or 867Mbps
Mode
There are four kinds of wireless mode selections:
AP
Client
WDS
AP+WDS
If you select WDS or AP+WDS, please click “WDS Settings” in the
submenu for the related configuration. Furthermore, click “Multiple
AP” to enable multiple SSID functions.
Network Type
In Infrastructure, the wireless LAN serves as a wireless station. And
the user can use the PC equipped with the
WDAP-C7200AC/WDAP-W7200AC to access the wireless network via
other access points. In ad hoc, the wireless LAN will use the ad-hoc
mode to operate.
Default is “Infrastructure”.
Note: Only while the wireless mode is set to “Client”, then the
Network Type can be configured.
SSID
It is the ID of the wireless network. User can access the wireless
network via its ID. However, if you switch to Client mode, this field
becomes the SSID of the AP you want to connect with.
Default: Planet AP 5G
Broadcast SSID
If you enable “Broadcast SSID”, every wireless station located within
the coverage of the WDAP-C7200AC/WDAP-W7200AC can discover
its signal easily. If you are building a public wireless network, enabling
this feature is recommended. In private network, disabling “Broadcast
