Planmeca ProMax User Manual

TABLE OF CONTENTS
2 Planmeca ProMax 3D Max with ProTouch
User’s Manual
The manufacturer, assembler, and importer are responsible for the safety, reliability
and performance of the X-ray unit only if:
- installation, calibration, modification and repairs are carried out by qualified
authorized personnel
- electrical installations are carried out according to the appropriate requirements
such as IEC 60364
- equipment is used according to the operating instructions
Planmeca pursues a policy of continual product development. Although every effort is
made to produce up-to-date product documentation this publication should not be
regarded as an infallible guide to current specifications. We reserve the right to make
changes without prior notice.
COPYRIGHT PLANMECA
Released: 14 November 2013
Publication part number: 10033254 revision 4
17 TECHNICAL SPECIFICATIONS ....................................................................55
17.1 Technical data for Planmeca ProMax product family ................................................... 55
17.2 Original manufacturer .................................................................................................. 58
17.3 Dimensions in mm (in.) ................................................................................................ 59
17.4 Minimum operational space requirements ................................................................... 59

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
