Plockmatic SR 85 - REP 1.3 Panels + Infeeder

Bookletmaker SR 85 February 2001PAGE
REP 1.3 Panels + Infeeder
REMOVAL
1. Loosen the four 7 mm screws (1).
2. Slide the top of the panels (2) away from the screws. Remove the shelf (3), remove the
two panels.
3. Loosen the four 7 mm screws (4).
4. Lift up the infeeder (5) and remove it.
INSTALLATION
Installation is an exact reversed procedure of removal.
1
2
2
3
4
5
1.3.1
