60
Appendix D
01.4IB.48041
BriteSpot® Plus
Table AB MODBUS Memory Map (cont.)
Register Name
Read /
Write
Register
Type
Description Default
Range,
format:
UOM Register #
Modbus
Oset #
Interpretation
BriteSpot® Fiber Power - 30348 to 30365
Fib Power 1 R Input Fiber Power of Ch 1 N/A
0 - 10,
0x7FFF
N/A 30348 349
0x7FFF - BriteSpot® module error
Fib Power 2 R Input Fiber Power of Ch 2 N/A
0 - 10,
0x7FFF
N/A 30349 350
Fib Power 3 R Input Fiber Power of Ch 3 N/A
0 - 10,
0x7FFF
N/A 30350 351
Fib Power 4 R Input Fiber Power of Ch 4 N/A
0 - 10,
0x7FFF
N/A 30351 352
Fib Power 5 R Input Fiber Power of Ch 5 N/A
0 - 10,
0x7FFF
N/A 30352 353
Fib Power 6 R Input Fiber Power of Ch 6 N/A
0 - 10,
0x7FFF
N/A 30353 354
Fib Power7 R Input Fiber Power of Ch 7 N/A
0 - 10,
0x7FFF
N/A 30354 355
Fib Power 8 R Input Fiber Power of Ch 8 N/A
0 - 10,
0x7FFF
N/A 30355 356
Fib Power 9 R Input Fiber Power of Ch 9 N/A
0 - 10,
0x7FFF
N/A 30356 357
Fib Power 10 R Input Fiber Power of Ch 10 N/A
0 - 10,
0x7FFF
N/A 30357 358
Fib Power 11 R Input Fiber Power of Ch 11 N/A
-50 - 200,
-999,
0x7FFF
N/A 30358 359
Fib Power 12 R Input Fiber Power of Ch 12 N/A
0 - 10,
0x7FFF
N/A 30359 360
Fib Power 13 R Input Fiber Power of Ch 13 N/A
0 - 10,
0x7FFF
N/A 30360 361
Fib Power 14 R Input Fiber Power of Ch 14 N/A
0 - 10,
0x7FFF
N/A 30361 362
Fib Power 15 R Input Fiber Power of Ch 15 N/A
0 - 10,
0x7FFF
N/A 30362 363
Fib Power 16 R Input Fiber Power of Ch 16 N/A
0 - 10,
0x7FFF
N/A 30363 364
Fib Power 17 R Input Fiber Power of Ch 17 N/A
0 - 10,
0x7FFF
N/A 30364 365
Fib Power 18 R Input Fiber Power of Ch 18 N/A
0 - 10,
0x7FFF
N/A 30365 366
EcoVisor™ 1 (Environmental Equipment Monitor) - 30400 to 30408
Serial Number Low Word R Input EcoVisor Serial Number Low N/A 0 - 65535 N/A 30400 401
Serial Number High Word R Input EcoVisor Serial Number High N/A 0 - 65535 N/A 30401 402
HW Part R Input EcoVisor HW Part Number 10230 0 - 65535 N/A 30402 403
FW Rev R Input EcoVisor Firmware Revision N/A 0 - 65535 N/A 30403 404
Temperature R Input Temperature N/A -40 - 80 °C °C / °F 30404 405
Relative Humidity % R Input Relative Humidity N/A 0 - 100 %RH 30405 406
R Input 30406 407
Dust Thickness R Input Dust Thickness N/A 0 - 400 um 30407 408
Dust Grayscale R Input Dust Grayscale Color N/A 0 - 100 % 30408 409
EcoVisor™ 2 (Environmental Equipment Monitor) - 30410 to 30418
Serial Number Low Word R Input EcoVisor Serial Number Low N/A 0 - 65535 N/A 30410 411
Serial Number High Word R Input EcoVisor Serial Number High N/A 0 - 65535 N/A 30411 412
HW Part R Input EcoVisor HW Part Number 10230 0 - 65535 N/A 30412 413
FW Rev R Input EcoVisor Firmware Revision N/A 0 - 65535 N/A 30413 414
Temperature R Input Temperature N/A -40 - 80 °C °C / °F 30414 415
Relative Humidity % R Input Relative Humidity N/A 0 - 100 %RH 30415 416
R Input 30416 417
Dust Thickness R Input Dust Thickness N/A 0 - 400 um 30417 418
Dust Grayscale R Input Dust Grayscale Color N/A 0 - 100 % 30418 419
