Power Electronics SD700 Series - G19: Fine Tuning - S19.2: MTR Load; G19: Fine Tuning - S19.3: MTR Model; G21: Networks - S21.1: ETHERNET

SD700
POWER ELECTRONICS
100
CONFIGURATION REGISTER
PARAMETERS
FACTORY SETTINGS
SETTING 1
SETTING 2
7 SUBNET B=255
255
___________________
___________________
8 SUBNET C=255
255
___________________
___________________
9 SUBNET D=0
0
___________________
___________________
10 GATEWAY A=0
0
___________________
___________________
11 GATEWAY B=0
0
___________________
___________________
12 GATEWAY C=0
0
___________________
___________________
13 GATEWAY D=0
0
___________________
___________________
14 MAC A=0
0
___________________
___________________
15 MAC B=80
80
___________________
___________________
16 MAC C=194
194
___________________
___________________
17 MAC D=114
114
___________________
___________________
18 MAC E=X
X
___________________
___________________
19 MAC F=Y
Y
___________________
___________________
G21: Networks – S21.2: MODBUS TCP
1 MIPtout=OFF
MODBUS TCP TOUT
OFF
___________________
___________________
G21: Networks – S21.3: ETHER./IP
1 CONTROL MODE=0
0
___________________
___________________
2 REFEREN.MODE=0
0
___________________
___________________
3 FAULT MODE = PE BEHV
PE BEHN
___________________
___________________
