Power Electronics SD700 Series User Manual

SD700
POWER ELECTRONICS
40
DESCRIPTION OF PROGRAMMING PARAMETERS
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
3 MIN1 RNG=+0%
MIN RANG ANAOUT1
G8.2.3 / Low of
range selection
Analogue Output
1
-250% to
+250%
Minimum level of analogue output 1.
Minimum level setting can be higher than the maximum level setting. This allows
the user to achieve inverse scaling. i.e. an increase in magnitude of the analogue
input would result in an output frequency decrease and vice versa.
YES
4 MAX1 RNG=+100%
MAX RANG ANAOUT1
G8.2.4 / High
range selection
of Analogue
Output 1
-250% to
+250%
Maximum level of analogue output 1.
Maximum level setting can be lower than the minimum level setting. This allows
the user to achieve inverse scaling. i.e. an increase in magnitude of the analogue
input would result in an output frequency decrease and vice versa.
YES
5 FILTER 1=OFF
FILTER ANAOUTPU1
G8.2.5 / Filter
selection for
Analogue Output
1
OFF=0.0 to
20.0s
Filter for analogue input 1 value.
If the analogue signal appears slightly unstable, improved stability and response
can be achieved with the addition of a suitable filter value.
Note: Filter use can add a slight delay to the analogue output signal.
YES
6 ANLG OUT 2=02
G8.2.6 / Mode
selection
Analogue Output
2
00 – 27
Analogue output 2 is programmable. See parameter 'G8.2.1 ANLG OUT 1' for
options table.
NO
7 FORMT 2=4-20 mA
G8.2.7 / Format
selection for
Analogue Output
2
0-10V,
±10V,
0-20mA,
4-20mA.
Analogue output 2 is programmable in one of four possible formats according to
the system requirements.
NO
8 MIN2 RNG=+0%
MIN RANG ANAOUT2
G8.2.8 / Low
range selection
of Analogue
Output 2
-250% to
+250%
Minimum level of analogue output 2.
Minimum level setting can be higher than the maximum level. This allows the user
to achieve inverse scaling. i.e. an increase in magnitude of the analogue input
would result in an output frequency decrease and vice versa.
YES
9 MAX2 RNG=+100%
MAX RANG ANAOUT2
G8.2.9 / High
range selection
of Analogue
Output 2
-250% to
250%
Maximum level of analogue output 2.
Maximum level setting can be lower than the minimum level. This allows the user
to achieve inverse scaling. i.e. an increase in magnitude of the analogue input
would result in an output frequency decrease and vice versa.
YES
10 FILTER 2=OFF
FILTER ANAOUTPU2
G8.2.10 / Filter
selection for
Analogue Output
2
OFF=0.0 to
20.0s
Filter for analogue output 2 value.
If the analogue signal appears slightly unstable improved stability and response
can be achieved with the addition of a suitable filter value.
Note: Filter use can add a slight delay to the analogue output signal.
YES
