Table F. Remote EPO
REMOTE
EPO
SWITCH
WIRES (2)
Remote EPO switch. rating is 24 VDC.
I
Amp minimum if supplied by user.
NOlE:
This
awttch
must
be
a
dedicated
switch, and not tied into any other cIrcuita
4.
If
you are installing multiple Remote EPO stations, wire additional stations in
parallel with the first Remote EPO.
I
-
5. If required, install
l/2”
conduit and wiring from the Remote EPO station to trip
circuitry of upstream protective devices. A normally open contact is provided,
as shown in Table F on page 48. Remote EPO switch wiring must be in
accordance with UL Class II.
6.
Secure the UPS by reversing all steps taken to prepare
k
for Remote EPO
installation.
Powe~~are
plus
80
UPS
Installation Manual
