Keep these notes in mind while installing the UPS:
l Dimensions in this book are in millimeters (inches).
l Do not tilt the UPS or other cabinets more than 210’ during installation.
l Coolind exhaust airffow is approximately 614.0 US (1300 CFM).
l The condutt landing plates are to be removed, to add conduit landing holes
as required. Plate material is 16 gauge steel (O6 inches thick).
l Terminals El - El 5 are UL and CSA rated at WC. A hex key tool is
required to attach wires to the terminals.
l The remote Emergency Load Cff feature opens all breakers and contactors
in the UPS cabinet and isolates power from your critical load. Local
;ectncai codes may also require tripping upstream protective devices to the
l If perforated floor tiles are required for ventilation, place them in front of the
UPS. The weight and point loading of the UPS cabinet are: (
_
Maximum WeigM
1205 kg (2650 Ibs)
Maxtmum Average Point Loading:
6 at 200 kg (440 Ibs) with casters
4 at 200 kg (662 Ibs) without casters
l Details about control wking are provided in each procedure for connecting
options and features. Table N on page A-4 identifies the control wiring
terminations.
12
l :
l
P~~erware Plus 80 UPS lnstaflation Manual
