PREVOST X3-45 User Manual

Coach Exterior
6
ENGINE COMPARTMENT
ENGINE COMPARTMENT CURB-SIDE DOOR
The engine compartment curb-side door
provides access to the following (if equipped):
• Engine compartment rear doors release
handle;
• Booster terminals;
• Fuel filter/water separator (Optional);
• Air circuit fill valve and drain cock;
• Sump tank access cap;
• Cold weather starting fluid bottle;
• 110 - 120 volt connector;
• Lavatory maintenance valve and
connectors;
• Fresh water reservoir fill connector;
• Coolant heater system.
ENGINE COMPARTMENT CURB-SIDE DOOR 18559
This door can be locked or unlocked using the
exterior compartment key or, if so equipped, by
the central door locking system. To open, push
sideways on the small lever located between the
marker lights.
NOTE
This compartment can be locked/unlocked
using the central locking system by pressing
the switch located on the L.H. side dashboard
panel.
ENGINE COMPARTMENT R.H. SIDE 18607
A telltale light illuminates when one or more
compartments are unlocked.
ENGINE COMPARTMENT REAR DOORS
To open the engine compartment rear doors,
open the engine compartment curb side door
and pull the handle located on the rear door,
close to the bottom door hinge.
WARNING
Unless otherwise stated, do not run the
engine when the engine compartment is
open.
These doors swing out to provide access to the
following:
• Engine;
• Alternator(s);
• Compressor(s);
• Belt tension control valve (refer to chapter,
Care and Maintenance);
• Engine starting selector (refer to chapter,
Starting and Stopping Procedures);
• Coolant line shutoff valves;
• Certification plates;
• Engine coolant surge tank;
• Air filter restriction indicator;
• Engine oil dipstick;
• Engine oil reserve tank;
• Power steering fluid reserve tank;
• Allison automatic transmission fluid dipstick;
• Engine coolant filler cap.
