Coach Exterior
11
WARNING
Although a powerful spring assists in reclining
the bumper, it remains heavy and rests low
when open. Caution should be used when
reclining.
Check that bumper is securely closed shut
before driving.
FUEL FILLER DOOR
The fuel filler door is located on the R.H. side of
the coach providing easy fuel filling. A spring
keeps the door either open or shut. A key is
provided for unlocking the door if the option was
chosen.
FUEL FILLER DOOR 03046
NOTE
Provided the vehicle is parked on level
ground, an automatic nozzle will automatically
shut off when tank is approximately 95% full.
NOTE
The fuel filler door must be in the unlocked
position before closing
CAUTION
Do not fill to more than 95% of the tank
capacity. Do not "top off" the tank, doing so
may result in fuel spillage when the fuel
expands.
ENTRANCE DOOR
Lock or unlock the entrance door from outside
the vehicle by turning the key in the door lock
(counterclockwise to lock, clockwise to unlock).
From outside, open the door by pushing the
switch forward, close by pushing the switch
rearward.
The only way to unlock the entrance door from
the inside is by sliding its lock lever to the left. If
the orange tab on the door-lock lever is visible,
the door is unlocked.
ENTRANCE DOOR EXTERIOR SWITCH
18599
From the inside, open the door by pressing the
door opening switch (L.H. button) on the R.H.
dashboard panel. Close by pressing the door
closing switch (R.H. button) on the dashboard.
Refer to “Controls and Instruments” chapter for
more information.
ENTRANCE DOOR & WIPER CONTROL PANEL 06614
