Coach Interior
22
WASTE CONTAINER
The waste container is located on the lavatory
wall, and is accessible through an opening on
each side of the wall. A small door, located on
the aisle side, gives access to the waste
container for cleaning.
GALLEY
The optional galley may include features such
as a microwave oven and refrigerator to
accommodate hot or cold food and beverage
service. The galley's electrical power circuit is
activated by a rocker switch located on the
dashboard. Refer to “Controls & Instruments”
chapter.
LAVATORY
The lavatory is located in the rear curb side
corner of the coach. It is equipped with a
chemical flush toilet, bathroom tissue dispenser,
wash-basin, towel dispenser, waste container,
mirror, ashtray, and a hose outlet in a
compartment located over the mirror. A liquid
soap dispenser and moist towel dispenser are
optional.
Locking the lavatory door from the inside will
illuminate a fluorescent light in the lavatory and
two outside signs to indicate occupation. One
sign is located on the outer wall of the lavatory
and another sign is located over the windshield.
A telltale light on the dashboard will illuminate to
inform the driver when the lavatory is occupied.
A night-light is permanently lit in the lavatory
when the ignition switch is in the ON position.
If emergency assistance is required, the lavatory
occupant can actuate a buzzer that will sound in
driver's area. The buzzer's push-button (c/w
instruction label) is located on the inner curbside
wall of lavatory.
The lavatory has its own ventilation system that
operates only when the ignition switch is in the
"ON" position.
NOTE
This fan runs constantly when the ignition
switch located on the dashboard is in the "ON"
position.
LAVATORY 23235
