Controls and Instruments
40
A low air pressure indicator LED (bottom right
corner of gauge) illuminates when the primary
air system pressure drops below 66 psi (455
kPa). An audible alert signal also informs the
driver of low air pressure. Refer to Safety
Features and Equipment chapter for table of
audible alerts. If the air pressure drops below
40 psi (276 kPa), the emergency brake applies
at full capacity.
DANGER
Do not drive the coach when air pressure is
low.
Secondary System Air Pressure (Front)
06227
Indicates the secondary air
system pressure. The normal
operating pressure is from 95
to 125 psi (655 to 860 kPa).
A low air pressure indicator LED (bottom right
corner of gauge) illuminates when the
secondary air system pressure drops below 66
psi (455 kPa). An audible alert signal also
informs the driver of low air pressure. Refer to
Safety Features and Equipment chapter for
table of audible alerts. If the air pressure drops
below 40 psi (276 kPa), the emergency brake
applies at full capacity.
DANGER
Do not drive the coach when air pressure is
low.
Vehicle Clearance Information
06447
Normal vehicle clearance is 11' 2" (3,40 m).
WARNING
Vehicle clearance is higher when the
ventilation hatch is open; if Hi-Buoy is
activated or if additional equipment is installed
on the roof.
TELLTALE PANEL
TELLTALE PANEL 06614
Some telltale lights described below appear on
the telltale panel only if the corresponding
optional equipment is installed on the vehicle.
Wheelchair Lift Door Ajar
06299
Illuminates when the wheelchair lift
compartment door and/or the
wheelchair access door are open.
The parking brake is activated
when this door is open. Refer to
Other Features chapter.
WARNING
Opening the door at a speed under 5 mph (8
km/h) will activate the parking brake and sound
an audible alert.
Lavatory Door Locked
Illuminates when the lavatory door
is locked.
