Other Features 79
Lower the platform to minimum height using the
telescopic leg cranks before moving it.
WARNING
For better stability, keep the platform at
minimum height when moving.
WARNING
Never deploy the platform from enclosure
while standing on the telescopic legs.
WARNING
Telescopic legs were designed to support and
move the platform only, do not use as a work
table.
WARNING
Before moving platform, make sure that floor
is level and free of obstacles.
WHEELCHAIR LIFT INSTALLATION
Raise the platform to proper level.
Insert the platform so that the rear carriage
clears the stops.
Turn telescopic leg crank until the carriage
comes in contact with the rails.
Remove the two rear telescopic legs from the
platform.
Insert the platform until the front carriage clears
the stops.
Lower the front of the platform.
Remove the two front telescopic legs from the
platform.
Push firmly and make sure that the platform
manual release shafts have turned to lock the
platform.
Secure the 4 fixing bolts located inside
compartment, on each side of platform. Apply a
torque of 60 lbf-ft.
Reconnect connector located at compartment
ceiling.
WARNING
When re-inserting platform into compartment,
make sure that carriage wheels are properly
aligned over the L. H. side triangular rail
before removing telescopic legs.
