ProMinent DULCOMETER User Manual

1 Operating Concept
A1035
1.
Fig. 1: Operating cross (1) / Active keys appear [black] in the display; inactive keys
appear [grey].
For example, the following path is illustrated:
Continuous display ➨ ➨ or [Calibrate] ➨ ➨ or [Slope] ➨ ➨
Continuous display
[Calibrate] [Slope]
A1036
Fig. 2: The display changes throughout an action.
I. Continuous display 1
II. Display 2
III. Display 3
IV. Display 4
The function of the keys is described in table Ä Chapter 1.1 ‘Functions of the keys ’
on page 11 .
➨ = describes as a symbol an action by the operator, that leads to a new possibility for
an action.
[Named in the display] = square brackets contain the name that appears identically
worded in the controller's display.
Use the key to call up further information.
Operating Concept
8

ProMinent DULCOMETER Specifications

General

Protection Class	IP65
Measurement Parameters	pH, Conductivity, Temperature
Communication	Modbus
Power Supply	24 V DC or 100-240 V AC
Control Outputs	Relay, Analog (0/4-20 mA)
Control Functions	PID control
Input Signals	Analog (0/4-20 mA), Digital
Mounting	Wall-mounted, panel-mounted
Measurement Range pH	0-14 pH
Measurement Range Conductivity	0-2000 µS/cm
