6.3.4 Wall mounting and control panel installation
Seals and terminal diagram
Select the correctly fitting seals for the controller's cable openings. Seal the open
holes with blanking plugs. This is the only way to ensure an acceptable air-tightness.
Moisture in the controller can lead to operational abnormalities.
Note the instructions on the terminal diagrams provided.
Sets, mounting fittings, part number 1045171, contains the following components
Description Part number Quan‐
tity
Seal (M 20 x 1.5), 4xØ5 1045172 2
Seal (M 20 x 1.5), 2xØ4 1045173 2
Seal (M 20 x 1.5), 2xØ6 1045194 2
Sealing stopper, Ø10, polyamide, grey RAL 7035 1042417 5
Protective plug, IL4-073 140448 5
Plug, IL4-044 140412 5
Threaded cable connector (M 20 x 1.5) (5-13), polya‐
mide, black
1040788 1
Threaded cable connector (M 12 x 1.5) (4-6), black 1009734 1
Counter-nut (M 12 x 1.5), width across flats 15), brass,
nickel-plated
1018314 1
Ensure that the cable is not under tension.
1. Loosen the four housing screws
Assembly and installation
43
