1.1 Functions of the keys
Functions of the keys
Key Function
Confirmation in the setting menu: Confirms and saves the input values.
Confirmation in the continuous display: Displays all information about
saved errors and warnings.
Back to the continuous display or to the start of the respective setting
menu, in which you are currently located.
Enables direct access to all of the controller's setting menus.
Enables direct access to the controller's calibration menu from the contin‐
uous display.
Start/Stop of the controller's control and metering function from any dis‐
play.
To increase a displayed number value and to jump upwards in the oper‐
ating menu.
Confirmation in the setting menu: Moves the cursor to the right.
Confirmation in the continuous display: Displays further information about
the controller input and output values.
Operating Concept
11
