8 Setting measured variables
n User qualification: trained user, see
Ä Chapter 4.4 ‘Users' qualifications’ on page 21
Continuous display ➨ ➨ or
[Measurement]
➨
[Measurement]
➨ or
[Meas. channel 1]
➨ or
[Measured variable]
Settings for [Channel 2]
In its 2-channel version, the controller has two measurement channels. This descrip‐
tion for [Channel 1] applies correspondingly for the settings in [Channel 2]. The pro‐
cedure for making the settings for the channel in question is identical, however the
parameters to be set may be different. Differences are pointed out and are also
described.
Channel 1
Measured variable
A1082
Chlorine
Sensor type
Measuring range
Temperature
Process temperature
pH compensation
CLE3/CLE3.1
0... 2.0 ppm
Manual
10.0 °C
Off
Fig. 27: Setting measured variables, using the example of [Channel 1] and the measured
variable [Chlorine]
The following measured variables can be set at the controller:
Measured variable Meaning Unit
[None]
The controller does not carry out any
measurement.
[pH [mV]]
pH sensor with mV signal
[pH]
[pH [mA]]
pH sensor with mA signal
[pH]
[ORP [mV]]
ORP sensor with mV signal
[mV]
[ORP [mA]]
ORP sensor with mA signal
[mV]
