15.1 Setting the [mA outputs]
Continuous display ➨ ➨ or [mA outputs] ➨ [mA outputs] ➨ or
[mA output 1] [Function] Set function
mA output 2 / mA output 3
Menu items [mA output 2] and [mA output 3] have the same setting options as menu
item [mA output 1]. A separate description is not provided. [mA output 3] is located
on the extension module and is only available if packages 2, 3 or 4 have been
selected with channel 2 in the identity code.
mA-output 1
Function Measured value
A0985
Output range
Current on error
0 mA
20 mA
Damping
HOLD reaction
0 ... 20 mA
23 mA
-1,45 pH
15,45 pH
high
HOLD
Assignment Channel 1
Fig. 99: Setting [mA output 1]
[Func‐
tion ]
Adjustable value Explanation
[Function] [Off] The mA output has no function
[Measured value]
[Control variable]
[Correction value] Temperature
The mA output is held at the valid mA output value upstream of [Pause Hold] .
Setting the [mA outputs]
