ProMinent DULCOMETER User Manual

Key Function
To decrease a displayed number value and to jump down in the operating
menu.
Moves the cursor to the left.
1.2 Changes the set operating language
1.
Simultaneously press the keys and
ð
The controller changes to the menu for setting the operating language.
A1482
Language
2
Language
German
Fig. 5: Menu for setting the operating language
2.
Now using keys and you can set the desired operating language
3.
Confirm your selection by pressing the key
ð
The controller changes back to the continuous display and indicates the
selected operating language.
Operating Concept
12

ProMinent DULCOMETER Specifications

General

Protection Class	IP65
Measurement Parameters	pH, Conductivity, Temperature
Communication	Modbus
Power Supply	24 V DC or 100-240 V AC
Control Outputs	Relay, Analog (0/4-20 mA)
Control Functions	PID control
Input Signals	Analog (0/4-20 mA), Digital
Mounting	Wall-mounted, panel-mounted
Measurement Range pH	0-14 pH
Measurement Range Conductivity	0-2000 µS/cm
