Pegasus R6, R4 Product Manual
8
Daisy-Chaining Multiple Pegasus Units
To daisy-chain multiple Pegasus units:
1. Connect a Thunderbolt cable from one of the Thunderbolt ports on the back
of your Mac computer to one of the Thunderbolt ports on the first Pegasus
unit.
2. Connect a second Thunderbolt cable from other Thunderbolt port on the first
Pegasus unit to one of the Thunderbolt ports on the second Pegasus unit.
See Figure 4.
Figure 4. Thunderbolt daisy-chain connections
Thunderbolt cable
iMac
(shown as an
example)
Thunderbolt
ports
Pegasus
unit 2
Pegasus
unit 1
Thunderbolt
ports
Thunderbolt
ports
