Chapter 5: Troubleshooting
115
Subsystem Problems
Subsystem problem troubleshooting includes:
• Diagnosing a Subsystem Problem (below)
• Overheating (page 116)
• Power Supply (page 117)
Diagnosing a Subsystem Problem
Check System Status on the Dashboard tab. If a yellow ! or red X
appears in the System Status box:
1. Click the name link of the component with the red X icon.
Figure 7. System Status box on the Dashboard
The list containing the problem component displays. In the case of a high-
temperature issue, shown in the example above, the Component List
displays.
2. For physical drives, disk arrays, logical drives, and spare drives, mouse-over
the component with the red X icon and click the View button.
Click the link beside
the red X icon
