Promise Technology Vess A6120 - Page 34

HDD Power
Drive carrier LEDs
HDD Status
& Activity
Management network port LEDs
Link/Activity
Port Speed
LED Description
Link/Activity ThisislitYELLOWwhenaphysicallinkisestablished;
itblinksYELLOWwhenthereisactivityontheport.
PortSpeed GREENindicates1000Mbps.
YELLOWindicates100Mbps
Unlitindicates10Mbps(ornolink).
22
Vess A6000 Series NVR Server Promise Technology
