Chapter 6: Tekterm Application
Port Scan-See Parameters
312
Psion Teklogix 7535/7530 Hand-Held Computer User Manual
6.20.3 Port Scan-See Parameters
When ‘Scan-See’ is specified as the peripheral for a port, the parameters listed under
the “Scan-See” sub-menu are used to tailor the operation of this type of scanner. The
other parameters listed in this menu – “Character Set”, “Baud” and so on – are
identical to those described beginning on page 308.
6.20.3.1 Scan-See Sub-Menu – Mapping The Viewport
The Scan-See display is mapped to a specific area on the 7535/7530 screen – called
the viewport – and is continuously updated to reflect that portion of the screen. The
Scan-See viewport is defined as follows:
Character Set»
Baud 9600
Data Bits8
Paritynone
Stop Bits1
Retries3
Input Tmo2
Scan See
05
Character Set »
Baud 9600
Data Bits 8
Parity none
Stop Bits 1
Retries 3
Input Tmo 2
Scan-See »
05
Scan-See
Range
Anchor Line 1 0...1
Anchor Column 19 0...19
Follow Cursor Y Y/N
Line Offset 0 -25...25
Column Offset 0 -80...80
Wraparound N Y/N
Panning Y Y/N
Line Scrolling N Y/N
Brightness 3 0 to 5
Arrows Bright Bright Horz Vert
Version 2 0...2
