SECTION 3
OPERATING PRINTER
34
Control Panel Keys
1.
QUICK MENU KEY – Allows quick access to often-used Printer functions without having to scroll
through a number of screens. Test Feed/Reprint, Horizontal and Vertical Alignment, Printer
Preferences, Purge Print, and Ink Status.
Press Quick Menu key again to return to previous screen.
2.
SHUTDOWN/RESTART KEY – The Shutdown Printer screen opens with the following button options:
Restart, Shutdown, USB Disconnect, Port Reset and Cartridge Initialize.
Shutdown button safely powers-down printer electronics.
IMPORTANT: Wait for cursor to stop blinking, or to disappear, before turning OFF Main Power Switch.
3.
PASS-THROUGH KEY – Press to access Transport Control screen. Use to temporarily run the Transport,
to clear media from under the Printheads.
4.
PAUSE/RESUME KEY – Provides a quick way to pause and resume a job at the Printer without using
the Touchscreen or computer. Press to start printing. Press to pause a running job. Press key again to
resume printing.
Quick Menu Key
Allows quick access to often-used Printer functions without
having to scroll through a number of screens.
Open by pressing the Quick Menu key on the Control
Panel. Press Quick Menu key again to exit the screen.
Test Feed/Reprint
Default is Test Feed. If no data is present, this
button allows you to test feed blank sheets of
media.
If you PAUSE the job or there is an Error (jam or
double feed), the Test Feed button becomes
Reprint. Recover missed or misprinted pieces by
pressing Reprint. Use the arrows to go back to the
initial misprinted piece (or further back if desired) to
start reprinting. Press Print. The Print Data screen
will appear to allow you to resume printing.
Purge Print
Prints an ink pattern at 600 dpi to clear all of the ink nozzles in all of the ink cartridges.
