APPENDIX A
72
APPENDIX A – Printer Specifications
PRINT TECHNOLOGY
Hewlett Packard Thermal Inkjet, 45-Style, High Capacity Cartridges
COMPATIBLE INK SUPPLIES
EASYInk - proprietary supplies designed for performance.
Genuine HP Original Cartridges, not refills or knock-offs, filled with proprietary ink
formulas. Available from your Quadient Distributor.
ADDRESS SPEED
(approximate maximum)
4” x 6” Postcards
34,000 /hour at 150 dpi
25,000 /hour at 200 dpi
20,000 /hour at 300 dpi
11,500 /hour at 600 dpi
#10 Envelopes
26,000 /hour at 150 dpi
19,000 /hour at 200 dpi
15,000 /hour at 300 dpi
7,200 /hour at 600 dpi
PRINT QUALITY (resolution v x h)
& SPEED SELECTIONS
150D (600 x 150 DPI) / SPEED 1, 2, 3, 4 (highest speed)
200D (600 x 200 DPI) / SPEED 1, 2, 3
300D (600 x 300 DPI) / SPEED 1, 2
600D (600 x 600 DPI) / SPEED 1 (lowest speed)
IMAGE AREA (maximum)
~3" x 17" (~76.2 mm x 431.8 mm)
PRINT UNIT CONFIGURATION
3 Pen + 3 Pen Stitched Design
MEDIA SIZE
(minimum to maximum)
Length: 5" to 17" (127 mm to 431.8 mm)
Width: 3" to 13.5" (76.2 mm to 342.9 mm)
MEDIA THICKNESS
Minimum: 0.008" (0.2 mm)
Maximum: 0.375" (9.5 mm)
MEMORY
1 GB of DDR3-1600Mhz SDRAM
16 GB microSD. Not externally accessible
FONTS
All TrueType fonts available on PC
INK MONITOR
Visible on display
FEEDER CAPACITY
Up to 750 #10 envelopes
SOFTWARE
Printer Drivers for Windows
TM
7/8/8.1/10
PC INTERFACE
Ethernet Port (10/100/1000Mhz)
USB 3.0 (USB 3.1 Gen 1) Port (also supports USB 2.0)
WiFi (wireless)
DIAGNOSTICS
Resident in firmware
FEED DIRECTION
Right-to-Left
PROCESSOR
600 MHz Dual-core ARM Cortex-A9 MPCore
FIRMWARE UPDATE
Via USB or replaceable MicroSD
DIMENSIONS
21.25" H x 28.75" L x 23" W (54 cm H x 73 cm L x 58.4 cm W)
WEIGHT
80 lbs. (36.3 kg.)
ELECTRICAL
Voltage: 115VAC or 230VAC (switchable)
Amperage: 1.6A @ 115V, 1A @ 230V
Frequency: 50/60 Hz
Fuse: 2x 1.6A, 250V, Slow-Blow (5x20mm)
COUNTERS
Lifetime Piece Counter, Session Counter, Jobs Counter
OPTIONS
Conveyor/Stacker, IR Dryer
All Specifications are Subject To Change Without Notice
