CHAPTER TITLE WEB GRAPHICAL USER INTERFACE (GUI) FOR ESMS
4-12
4.4 Web Graphical User Interface (GUI) for ESMS
Using the Web GUI
The BMC firmware features an embedded web server enabling
users to connect to the BMC using a Web browser (e.g. Micro-
soft Internet Explorer). The Web GUI shows system informa-
tion, system events, system status of managed servers, and
other system-related information.
The Web-based GUI is supported on the following browsers:
Internet Explorer 7 and above
Firefox 2.0 and above
Google Chrome 2.0 and above
Safari 3.0 and above
Opera 9.64 and above
Login
Enter the IP address or URL (default DHCP\static IP address)
into the address bar of the web browser.
When connecting to the BMC the Login screen prompts for the
username and password. This authentication with SSL protec-
tion prevents unauthorized intruders from gaining access to the
BMC web server.
When a user is authenticated they can manage the server
according to the privilege of their role.
The OEM Proprietary, Administrator and Operator privilege lev-
els are authorized to login to the web interface. The User and
No Access privilege levels do not allow access through the
BMC web GUI.
Figure 4-3. Login Web Page
Table 4-11: Default Username and Password
F
IELD DEFAULT
Username admin
Password admin
