INSTALLING HARDWARE REMOVING A 3.5” HARD DRIVE
2-4
Removing a 3.5” Hard Drive
Hard drives are grouped together so that each group of hard
drives is fixed to a specific node.
Figure 2-5. Opening the Hard Drive Tray Handle
1. Press the tray handle button.
Figure 2-6. Removing the 3.5” Hard Drive Tray
2. Pull the hard drive tray handle completely open.
3. Grasp the tray handle and pull the tray from the system.
WARNING!
Make sure the hard drive tray handle is in the fully open posi-
tion.
2
3
!
