QUANTA STRATOS S210 Series S210-X22RQ User Manual

CHAPTER TITLE WEB GRAPHICAL USER INTERFACE (GUI) FOR ESMS
4-42
Procedure:
1. Enable the RADIUS Authentication checkbox to authen-
ticate the RADIUS.
2. Enter the port number in the Port Number field.
3. Enter the time out value in seconds in the Time out field.
4. Enter the address of the server in the Server Address
field.
5. Enter the authentication secret for RADIUS Server in the
Secret field.
6. Click Save to save the entered details.
7. Click Reset to reset the entered details.
Remote Session
In MegaRAC SP, use this page to configure virtual media con-
figuration settings for the next redirection session. Encryption is
disabled by default.
To open Remote Session page, click Configuration > Remote
Session from the main menu. A sample screenshot of Remote
Session Page is shown in the screenshot below.
Figure 4-33. Remote Session
The fields of Remote Session Settings Page are explained
below.
Server Address
The IP address of RADIUS server.
Note:
 IP Address made of 4 numbers separated by
dots as in "xxx.xxx.xxx.xxx".
 Each Number ranges from 0 to 255.
 First Number must not be 0.
Secret
The Authentication Secret for RADIUS server.
Note:
 This field will not allow more than 31 charac-
ters.
 Secret must be at least 4 characters long.
 White space is not allowed.
Save To save the settings.
Reset To reset the modified changes.
Table 4-27: RADIUS Settings Page (Continued)
I
TEM DESCRIPTION
Table 4-28: Remote Session Settings Page
I
TEM DESCRIPTION
KVM Encryption
Enable/Disable encryption on KVM data for the
next redirection session.
