INSTALLING HARDWARE MEMORY MODULES
2-18
2.8 Memory Modules
General Guidelines
All multi-node servers have specific rules for the population of
memory on the individual mainboards that must be obeyed.
Refer to the following individual server rules for information on
how to populate the particular server required.
Removing a Memory Module
Remove the top cover. See Removing the Top Cover on
page 2-8.
1. Press down on the two memory module slot levers. The
memory module partially ejects.
The mainboard is supplied with all DIMM slots populated with memory 9 dummies for proper air flow. When installing and replacing
memory modules, only remove those dummies that are to be directly replaced. All DIMM slots must be occupied at all times by
either a memory module or dummy cover.
Memory modules remain hot after the system is powered
down. Allow sufficient time for the memory modules to cool
before handling system components.
