CHAPTER TITLE WEB GRAPHICAL USER INTERFACE (GUI) FOR ESMS
4-31
Network
In MegaRAC GUI, the Network Settings Page is used to config-
ure the network settings for the available LAN channels.
To open Network Settings page, click Configuration > Net-
work from the main menu. A sample screenshot of Network
Settings Page is shown in the screenshot below.
Figure 4-23. Network Settings Page
The fields of Network Settings page are explained below.
Table 4-23: Network Settings Page
I
TEM DESCRIPTION
LAN Interface Lists the LAN interfaces.
LAN Settings To enable or disable the LAN Settings.
MAC Address
This field displays the MAC Address of the
device. This is a read only field.
IPv4 Settings
This option lists the IPv4 configuration settings.
Obtain IP Address automatically: This option
is to dynamically configure IPv4 address
using DHCP (Dynamic Host Configuration
Protocol).
IPv4 Address, Subnet Mask, and Default
Gateway: These fields are for specifying the
static IPv4 address, Subnet Mask and
Default Gateway to be configured to the
device.
IP Address made of 4 numbers separated by
dots as in "xxx.xxx.xxx.xxx".
Each Number ranges from 0 to 255.
First Number must not be 0.
