MAINBOARD JUMPERS AND CONNECTORS MAINBOARD JUMPERS AND CONNECTORS
S210-X22RQ 5-4 TECHNICAL GUIDE
Table 5-2: User-Accessible Jumpers
JUMPER
LOCATION
DEFAULT
SETTING
FUNCTION
J30 1-2
PASSWORLD CLEAR
 1-2 : NORMAL
 2-3 : PASSWORD CLEAR
J16 1-2
PLD DEBUG MODE
 1-2 : DISABLE DEBUG MODE
 2-3 : ENABLE DEBUG MODE
J28 1-2
CMOS CLEAR
 1-2 NORMAL RTC 2-3 CLR
 RTC REGISTERS
J26 1-2
BIOS RECOVERY MODE
 1-2 : NORMAL OPERATION
 2-3 : RECOVER BIOS
J29 1-2
ME FIRMWARE UPDATE
 1-2: NORMAL MODE
 2-3: ME IN FORCE UPDATE
MODE
J25 1-2
QPI SLOW MODE SELECTION
 1-2 : QPI FAST MODE
 2-3 : QPI SLOW MODE (66MT/s)
J1E2
Non-
Pop
FORCE IBMC UPDATE
 Non-pop: NORMAL MODE
 1-2 : FORCE UPDATE MODE
J22
Non-
Pop
IBMC DISABLE
 Non-pop: NORMAL MODE
 1-2 : DISABLE BMC
J69
Non-
Pop
SPI SELECTION
 Non-pop : System BIOS used
 1-2 : BMC used
J6
Non-
Pop
RS232 SELECTION
 Non-pop : System used
 1-2 : BMC debug used
J7 OPEN MFG MODE (Reserved)
J5 OPEN
PBG INTRUDER DETECT
(Reserved)
Table 5-2: User-Accessible Jumpers (Continued)
JUMPER
LOCATION
DEFAULT
SETTING
FUNCTION
