Table 1-7: Rear LED Function and Behavior
N
AME COLOR CONDITION DESCRIPTION
ID LED
Blue ON
Unit selected
for identification
-OFF
No identifica-
tion requested
LAN1
LED
(Right)
Link/
Act
Green ON LAN Link
Green Black Blinking
LAN Access
(off when there
is traffic)
- OFF Disconnect
Speed
Green ON
Green, link
speed is
1000Mbits/sec
Amber ON
Amber, link
speed is
100Mbits/sec
-OFF
OFF, link speed
is 10Mbits/sec
LAN2
LED
(left)
Link/
Act
Green ON LAN Link
Green Black Blinking
LAN Access
(off when there
is traffic)
- OFF Disconnect
Speed
Green ON
Green, link
speed is
1000Mbits/sec
Amber ON
Amber, link
speed is
100Mbits/sec
-OFF
OFF, link speed
is 10Mbits/sec
Ser-
vice
Port
(LAN3)
LED
Link/
Act
Green ON LAN Link
Green Black Blinking
LAN Access
(off when there
is traffic)
- OFF Disconnect
Speed
Green ON
Green, link
speed is
1000Mbits/sec
Amber ON
Amber, link
speed is
100Mbits/sec
-OFF
OFF, link speed
is 10Mbits/sec
Table 1-7: Rear LED Function and Behavior
N
AME COLOR CONDITION DESCRIPTION
