RADWIN 5000 Installaon Guide
August 2023
10
Figure 16: Alpha / SU PRO / Air Integrated
3/5 GHz unit
Figure 17: Alpha / SU PRO / Air
Connectorized
1.2.4 External Antennas
RADWIN radios come with integrated or external antennas. RADWIN oers many kinds of external
antennas. Any external antenna (either provided by RADWIN or any 3
rd
party) is compable to any RADWIN
radio with external antenna connectors.
1.2.5 Method of Work
Both the base staons and the subscriber units communicate respecvely, with the service provider and
users. The communicaon protocol for both the service provider and the users is Ethernet. See Figure 18:
RADWIN 5000 General Connecon Scheme.
• A PoE device is connected to power and the communicaons network:
▪ On the base staon side, the PoE is connected to the backhaul network.
▪ On the subscriber unit side, the PoE is connected to end‐user equipment: routers, WiFi devices, etc.
• The radio units and PoE devices are also connected to ground.
• The Base Staon communicates with the Subscriber Unit or Units via the air interface.
These models shall be located in a Restricted Access Locaon and be accessible
only to a skilled person familiar with the unit construcon and possible hazards.
Check the voltage on the antenna connector before access. Possibility of
hazardous voltage 56VDC appearance exists on accessible antenna connecons.
Use Personal Protecon Equipment (e.g. insulang gloves) when working with
the units or antennas.
Connect the shield of antenna coaxial cable to protecve earth when a coaxial
cable is used.
