RADWIN 5000 Installaon Guide
August 2023
95
1
2
Single
Diversity
25 Mbps
1
1
Single
Single
25 Mbps
Site A and B may be HBS or SU.
B.4 Consideraons for Changing Antenna Parameters
Let:
max Available Tx Power denote the maximum Tx Power praccally available from an ODU. (It appears as Tx
Power per Radio.)
maxRegEIRP denote the maximum EIRP available by regulaon. It will be determined by three factors:
• per band/regulaon
• per channel bandwidth
• antenna gain
maxRegTxPower denote the maximum regulatory Tx Power for the equipment, also having regard the above
three points.
Then, the following relaonship must be sased:
maxAvailableTxPowe r min(maxRegEIRP
– AntennaGain + CableLoss max RegTxPower) ... (*)
The Tx Power (per radio) indicates the power of each radio inside the ODU and is used for Link Budget
Calculaons. The Tx Power (System) shows the total transmission power of the ODU and is used to calculate
the EIRP according to regulaons.
The inequality (*) above is always sased by the system in accordance with the relevant regulaon.
The Max EIRP level will be automacally set according to the selected band and
regulaon.
The precise relaonship between the items in inequality (*) is as follows: Required Tx Power (per radio) will
be adjusted down to the lesser of the value entered and maxAvailableTxPower
• Tx Power (system) is maxAvailableTxPower + 3 (for 2 radios)
• Max EIRP is maxRegEIRP.
• EIRP is maxAvailableTx Power + Antenna Gain ‐ Cable Loss
