e. Once the band is at the correct radius, close the clamp and ghten with a screwdriver (make sure
the tops of the screws face away from the mount):
3. Alternavely, you can fasten the mount with screws (not included) appropriate for the surface being
used:
2.7 Mounng the MulSector Base Staon Connectorized
The MulSector Connectorized unit can be mounted on a vercal pole or on a wall.

1. Recommended diameter of the pole is 2 to 4 in (5‐10 cm).
▪ Use worm‐drive clamps to install the supporng mount on a pole. The included worm‐drive clamps
support poles whose diameter is 2 to 4 in (5 to 10 cm).
