Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
92
Funcon
Color
PoE
LAN
TxRx D & Power(‐)
Brown
8
8
A.3 User Port Connectors
A.3.1 LAN Port
The LAN 10/100BaseT interface terminates in an 8‐pin RJ‐45 connector, wired in accordance to Table 6.
Table 6: Fast Ethernet Connector Pinout
Funcon
Signal
Pin
Transmit Data (posive)
TD (+)
1
Transmit Data (negave)
TD (–)
2
Receive Data (posive)
RD (+)
3
Receive Data (negave)
RD (–)
6
A.4 DC Power Terminals
A.4.1 DC PoE
DC power terminals are as follows:
Table 7: Terminal Block 2‐pin ‐48VDC
Funcon
Pin
+
Right
–
Le
