Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
6
1. Introducon
1.1 Scope of This Document
This document shows how to install RADWIN 5000 radios.
For a detailed descripon of how to congure RADWIN 5000 radios and sectors, see the RADWIN 5000
Conguraon Guides / User manuals.
1.2 RADWIN 5000 Overview
1.2.1 Sector
The RADWIN 5000 system consists of a “sector” that includes a base staon, and at least one subscriber
unit. The subscriber units are installed and work opposite the base staons.
Figure 1: A RADWIN 5000 Sector
1.2.2 Base Station
There are several types of base staons, all of which are High‐Capacity Base Staons (HBS):
