Figure 89: Input port: SU Connectorized unit (“PoE In”)
When working with the SU Connectorized unit ‐
Possibility of hazardous voltage 56VDC appearance exists on accessible antenna
connecons. Use Personal Protecon Equipment (e.g. insulang gloves) when
working with the unit or the antenna.
Connect the shield of antenna coaxial cable to protecve earth when coaxial
cable is used.
Unit shall be permanently connected to protecve earth by a skilled person using
min. 14 AWG wiring.
2.14.2 JET‐DUO 3/5 GHz, JET AIR, JET PRO, JET‐AIR DUO, NEO and NEO DUO Units
1. Connect a CAT‐5e cable to the “PoE IN” port of the radio as shown (the connecon on the NEO DUO and
JET‐AIR DUO is not labelled). This connecon provides power to the unit and can also serve as a
management and data connecon. It is referred to as “LAN1” in the Web user interface :
